Introduction

Hawker HuaDa EV series of power battery, is the international advanced level of lithium iron phosphate (LiFePO4) power battery system. With high energy density, long cycle life, excellent charge and discharge performance, good temperature performance, is a new generation of high security and high reliability of the green power supply.

This series of batteries is the use of the latest development of the battery management system (BMS), specifically for mobile mechanical equipment, online charging and wireless charging and design and production of power batteries, with advanced battery self-management, communication, alarm and short-term fast charge Complete function.



Product Features

● Excellent charge and discharge overvoltage and undervoltage protection

● provide analog output AO, SOC analog output 0 ~ 5V, user-friendly power monitoring

Note: SOC can only be used as a reference, can not be used as a decision.

● Provides a highly efficient passive equalization system

● Charge / discharge are all with short circuit insurance

● Panel LED power, system status display

● Rich interface, through the digital IO and 485 interface to achieve information exchange

● professional industrial design and material selection, sustainable work in the harsh industrial environment

● support high-power charge and discharge, to meet the needs of a variety of different industrial conditions

● wide temperature working environment conditions, -20 degrees -60 degrees

● small size



 Dimensions specifications





Types

Battery size

Long*wide*high（mm）

Charge continuous current

Discharge continuous current

EV24-40

315*237*165mm

80A

20A

EV24-60

315*240*215mm

320*237*188mm

460*220*150mm

120A

30A

EV24-80

355*330*215mm

160A

40A

EV24-100

355*330*215mm

200A

50A

EV24-120

400*275*245mm

180A

60A

EV24-200

550*210*425mm

200A

100A

EV48-30

345*238*200mm

60A

30A

EV48-60

590*240*240mm

120A

30A

EV48-80

585*345*230mm

160A

40A

EV48-100

585*345*230mm

200A

50A

EV48-160

605*435*255mm

160A

80A

EV48-200

615*650*250mm

160A

100A

EV48-250

605*290*480mm

200A

125A



Performance specifications

project

Features

Overvoltage protection

3.7V (single string)

Undervoltage protection

2.8V (single string)

Charging parameters

Maximum 2C lasts for 10 minutes, 1C continues

Discharge parameters

Up to 1C continuous

Charge and discharge port form

Charge and discharge

fuse

Have

RS-485 communication

Have

Analog output AO

Have

Configurable DO output

Have

Power LED display

Have

Master switch

Have

Operating temperature

-20℃~60℃

Storage temperature

-20℃~70℃

Working humidity

Relative humidity of 10% to 80%, no condensation

cooling system

Passive natural cooling

Charger requirements

Lithium iron phosphate battery charger

Battery shell color

Toyota White (customizable)

霍克-锂电池EV24-100【型号 参数 规格】

霍克-锂电池EV24-100【型号 参数 规格】

Detailed description

Hawker HuaDa AGV Safe series of lead-acid battery charger is a high-frequency switching power supply as the core, the main power converter using high-frequency high-permeability nanocrystalline transformers, microcomputer control of intelligent automatic charger.

High-tech applications, improve the efficiency of the whole conversion. Products with high efficiency, energy saving significant features, compared to traditional charger energy saving 20% -30%.

This series of microcomputer computer built-in a variety of battery charging program, accurate simulation of different types of battery charging curve. Choose a different charging program, can AGM, colloid, semi-colloidal and rich liquid water and other lead-acid batteries to charge.

The charging system consists of the charger and the charged battery to form a binary closed loop circuit. The dU / dt and dI / dt techniques are used to dynamically track the battery to accept the current. The microcomputer automatically determines the parameters of the on-line charging program according to the status of the battery, controls the output current and voltage Charging time, the charging current from the beginning to the end of the battery in the vicinity of the acceptable charge current curve, so that the battery almost no gas precipitation conditions. Not only save electricity, to achieve rapid charging, but also no damage to the battery to extend battery life. Current output is the pulse current mode, improve the battery charging capacity, reduce the concentration of polarization, electrochemical polarization, reduce gas generation. This is a very important way to reduce the battery temperature rise, reduce the battery plate deformation, reduce the gas flushing plate, reduce the active material off.

This series of charger with anti-battery reverse, the output short circuit, the output overload protection. Also has the function of automatic switch machine, can be connected to long-term input power. Need to charge, connect the battery pack, the charger work; no charge, disconnect the battery pack, the charger to stop working, the operation is very simple, user-friendly.

Hawker HuaDa intelligent automatic lead-acid battery charger is a high reliability, high stability of the new energy-saving lead-acid battery charger.

Specifications Model

Product model

Charging mode

Charging voltage / current

Battery capacity

Outline size

Net weight

Input power

Cell voltage

Ah

W*H*L(mm)

Kg



TP4-24

 Three stage constant current

24V/4A

20-40

195*150*340

7

1Ф220VAC

TP8-24

 Three stage constant current

24V/8A

45-70

195*150*340

7

1Ф220VAC

TP15-24

 Three stage constant current

24V/13A

60-100

195*150*340

7

1Ф220VAC

TP20-24

 Three stage constant current

24V/20A

100-150

195*150*340

7

1Ф220VAC

TP25-24

 Three stage constant current

24V/25A

150-210

195*150*340

7

1Ф220VAC

TP30-24

 Three stage constant current

24V/30A

180-250

195*150*340

8

1Ф220VAC

TP35-24

 Three stage constant current

24V/35A

240-320

200*160*360

9

1Ф220VAC



TP15-48

 Three stage constant current

48V/13A

60-100

195*150*340

7

1Ф220VAC

TP20-48

 Three stage constant current

48V/20A

100-150

195*150*340

8

1Ф220VAC

TP25-48

 Three stage constant current

48V/25A

150-210

195*150*340

9

1Ф220VAC

TP30-48

 Three stage constant current

48V/30A

180-250

200*160*360

9

1Ф220VAC

TP40-48

 Three stage constant current

48V/40A

240-320

200*160*360

10

1Ф220VAC

TP50-48

 Three stage constant current

48V/50A

360-420

265*180*420

15

1Ф220VAC



TP15-72

 Three stage constant current

72V/13A

60-100

195*150*340

8

1Ф220VAC

TP20-72

 Three stage constant current

72V/20A

100-150

195*150*340

9

1Ф220VAC

TP25-72

 Three stage constant current

72V/25A

150-210

200*160*360

10

1Ф220VAC

TP30-72

 Three stage constant current

72V/30A

180-250

200*160*360

12

1Ф220VAC



TP15-96

 Three stage constant current

96V/13A

60-100

195*150*340

8

1Ф220VAC

TP20-96

 Three stage constant current

96V/20A

100-150

200*160*360

10

1Ф220VAC

TP25-96

 Three stage constant current

96V/25A
